RTD2660H 1920x1200 resolution dual-port LVDS interface display android driver board for TFT LCD srceen
MT-R60H
Contact Us：
Product Description
MT-R60H is connected with TFT LCD panels used in liquid crystal display driver
board, this MONITOR program can support up to 1920x1200 resolution, color support to
24bit, line frequency of 15 to 250KHz, 45 to 80Hz field frequency range signal can be
synchronized automatically detect synchronization mode requires the use of horizontal
and vertical sync signals separated. Which program supports both DCR
(dynamic Contrast Ratio), external audio output, you can adjust the volume with the key
way NC.
| Model | MT-R60H | |
| Chip solution | Single Chip RTD2660H | |
| Screen Panel | Flooding screen interface | Single / dual-port LVDS interface |
| Maximum resolution | 1920x1200 | |
| Power supply | Operating Voltage | 12V or 12V +5 V |
| Flooding screen voltage | 3.3V or 5V or 12V | |
| Power Mode | Support low-power mode, standby mode | |
| Standby Power | <1W | |
| OSD language | Simplified Chinese, Traditional Chinese, English, French, German, Italian, Spanish, Japanese, Korean, Russian, Polish, Thai, Netherlands Language | |
| Key Functions | POWER, MENU, +/-, AUTO/EXIT | |
| Audio Output | 2x2W(8Q) | |
| Mode | Resolution | Horizontal Frequency (KHz) | Vertical frequency (Hz) | Standard |
| VGA | 640X480 | 31.469 | 59.940 | VESA |
| VGA | 640X480 | 37.500 | 75.000 | VESA |
| VGA | 640X480 | 37.861 | 72.809 | VESA |
| SVGA | 800X600 | 37.879 | 60.317 | VESA |
| SVGA | 800X600 | 48.077 | 72.188 | VESA |
| SVGA | 800X600 | 46.875 | 75.000 | VESA |
| XGA | 1024X768 | 48.363 | 60.004 | VESA |
| XGA | 1024X768 | 56.467 | 70.069 | VESA |
| XGA | 1024X768 | 60.023 | 75.029 | VESA |
| SXGA | 1280X1024 | 63.981 | 60.020 | VESA |
| SXGA | 1280X1024 | 79.976 | 75.025 | VESA |
| WUXGA | 1920X1080 | 66.290 | 59.954 | VESA |
| WUXGA | 2048X1152 | 72.000 | 60.000 | VESA |
