Product Description
GeneralSpecifications
Item | Specification | Unit |
LCD Size | 2.76 | inch |
Display Mode | NormallyBlack | |
Resolution | 480(RGB)x480 | Pixel |
Pixel pitch | 0.1461*RGB*0.1461 | mm |
Pixel Arrangement | RGB Vertical Stripe | |
Viewing direction | IPS | |
Module outline dimension | 73.03(H)*76.48(V)*2.34(D) | mm |
LCDAA | 70.13x70.13 | mm |
Colors | 16.7M | |
DriverIC | ST7701 | |
Interface | 3SPI+18RGB | |
Backlight | WhiteLED | |
Operating Temperature | -20℃~+70℃ |
