240*240 Knob Display 1.3 Inch Round Ips Tft Lcd Module Rotary Switch For Home Appliance
MTR013QV13A-V1
Contact Us：
Product Description
1. General Description
MTR013QV13A-V1 series module is a module that perfectly combines the display screen, encoder, push button and status LED into a rotating button display. The unique innovative structure and exquisite manufacturing process of the module make it have excellent reliability and excellent control experience. It is applicable to the demand of rotating button control in many industrial applications of electronic products.
1.1. Module serial port control function:
1. The module contains MCU. The TFT display is driven and controlled by the MCU and its peripheral device.
2. The module MCU has the communication function with the external HOST MCU according to the specified protocol, and can transmit control commands and display information to each other.
3. The GUI (graphical interface) of the module can be stored in the flash(flash size:16 megabytes) of the module, and can be customized according to the product application.
4. There is special software which can efficiently develop beautiful image and complex control GUI.
1.2. Product application:
1. Smart home appliances: smart refrigerators, household and commercial air conditioners, washing machines, stoves, entertainment electronic devices, and smart home central control modules.
2. Medical beauty products: medical testing instruments, health physiotherapy instruments.
3. Instruments: automobile monitor, motorcycle instrument, building management, security monitoring instrument.
4. Industrial control instruments: electromechanical equipment control display, charging equipment, elevator floor control and display, ordering machine.
2. Basic Parameters
1. 1.32 inch circular display 240*240 TFT/Serial port
2. Annular status LED indicator
3. EC2801-AX-15/11-15P3 encoder
4. Integral push button
5. AWG28 line standard 2.54mm/5 PIN
6. Three point standard screw installation
