10.1 Inch Screen RK3399 Android System 2GB & 16GB 1000M WIFI Modele Super Development Board
MT-3399
Enquiry
Product Description
Introduction:
MT-3399 is a high-end development board based on Rockchip RK3399. MT-3399 is the first 64-bit development board with super high performance based on industrial control. MT-3399 is incorporated with six cores: four A53 cores and two A72 cores. Its dominant frequency is up to 2GHz.
RK3399 is rated monster level in terms of CPU and GPU. Incorporating two Cortex-A72 large cores and four Cortex-A53 small cores, the CPU has been greatly improved in terms of integers, floating decimals, and memory as well as overall performance, power consumption, and core area.
The GPU is incorporated with a new-generation high-end ARM image processor Mali-T860, which contains four cores, integrated with more bandwidth compression technologies, such as intelligent superposition, ASTC, and local pixel storage. The GPU also supports more graphic and computing interfaces and its overall performance is 45% greater than that of the last generation products.
Although these capabilities are called top capabilities of the chip solutions of the same kind, they are not the key features of RK3399. RK3399 is highlighted in the Type-C interface, embedded PCI-E interface, and two cameras that support gesture recognition, which help overturn the experience in using the game box products. RK3399 also has other new features, such as supporting LPDDR4 memory, ahead of the current mainstream products.
Built upon high configuration and the improvement in the overall performance as well as comprehensive layout, RK3399 is born to be an all-rounder. Apart from the panel computer, VR, TVBOX, and laptop, RK3399 is applied to a diversity of terminals in the industry and consumption fields, including intelligent household appliances, advertising machines/integrated machines, financial POS terminals, vehicle-mounted control terminals, thin clients, VOIP video conferencing, security/surveillance/police affairs and Internet of Things.
| Hardware Interface Description: | ||
| Reference Sign | Name | Description |
| 1 | CPU | RK3399,A53,4x1.5GHz+A72,2x2GHz |
| 2 | DDR | K4E8E304EE-EGCF, LPDDR3, 2GBytes |
| 3 | eMMC | KLMAG2GEND, 16GB(4G, 8G optional) |
| 4 | RTC | RTC battery holder, CR1202 |
| 5 | UART | UART4, TTL level interface |
| 6 | BEEP | Buzzer |
| 7 | UART2 | Serial port 2, a default debugging serial port,RS232 level |
| 8 | DC holder | 5V DC power input |
| 9 | POWER | Power button |
| 10 | BOOT | Interface for burning programs of the single-chip microcomputer |
| 11 | Independent Buttons | Add volume; used as a Recovery button during upgrade |
| 12 | Independent Buttons | Decrease volume |
| 13 | Independent Buttons | Back button |
| 14 | Independent Buttons | Menu button |
| 15 | MIPI CSI | MIPI camera interface |
| 16 | MIPI CSI+DSI | MIPI camera interface and DSI interface, which can connect to two MIPI panels |
| 17 | MIPI DSI | Connecting to the screen with an MIPI interface |
| 18 | HDMI | HDMI output interface |
| 19 | RESET | Reset button |
| 20 | Infrared receiving head | HS0038 infrared integrated receiving head |
| 21 | TF card | TF card holder |
| 22 | TYPE-C | TYPE-C interface, compatible with OTG function |
| 23 | USB HOST | HOST2.0 interface |
| 24 | USB HOST | HOST3.0 interface |
| 25 | SIM card slo | 3G and 4G mobile phone card slot |
| 26 | PCIE interface | Connecting to 3G and 4G modules |
| 27 | EDP | EDP interface |
| 28 | GPIO interface | GPIO extension interface |
| 29 | LED | 4-channel programmable LED |
| 30 | Camera interface | Standard 24-pin parallel camera interface |
| 31 | MIC | Earphone, recording input |
| 32 | Speaker Interface | External two-channel speaker |
| 33 | SPDIF | Fiber output interface |
| 34 | Earphone holder | Earphone output |
| 35 | Gigabit network port | RT8211E interface |
| 36 | WIFI/BT | AP6354 WIFI/BT two-in-one module |
| Electrical Characteristics | |
| Main 3.3V input voltage | 3.3V/4.3A (3.3V/5A input recommended) |
| Secondary 3.3V input voltage | 3.3V/300mA (cannot be mixed with main 3.3V) |
| RTC input voltage | 2.5 to 3V/5uA |
| Output voltage | 1.8V(that can be used to supply power to the base plate; which is 0V after dormancy) |
| Operating temperature | -40°C~80°C |
| Storage temperature | -10°C~50°C |
